Tenda 8-Port Gigabit Network Switch (TEG1008M)
$55.00
- 【Expand your wired network】The network switch with 8 Gigabit Ethernet ports supports auto MDI / MDIX and auto-negotiation; Gigabit network switch supports up to 1000 Mbps, which is 10 times faster than Fast Ethernet, ensuring the transfer speed of large files; in full duplex mode, the transmission speed can reach 2000 Mbps
- 【Silent Operation】The fanless design ensures noiseless operation without disrupting the working environment, ideal for noise-sensitive environments
- 【Plug and Play】No configuration required; just plug the Ethernet cable into the port of your Ethernet switch and enjoy your high speed internet
- 【Metal Case】Full metal case ensures effective heat dissipation, more stable operation, and extends the service life of the Ethernet splitter
- 【Flexible Mounting】8 port Gigabit switch supports desktop or wall mount placement, suitable for different environments
or 4 payments of $13.75 with Wizit learn more
TEG1008M is a high-performance 8-port full Gigabit desktop Ethernet switch designed for Tenda’s high-speed cascading scenarios for small and medium-sized surveillance, small and medium-sized businesses. Designed with a mini steel shell, it does not take up space and has a strong heat dissipation. Provides 8 10/100/1000 Mbps auto-negotiation ports, which increases transmission rate by 10 times, improves large file forwarding rate, and effectively solves problems such as video jams and picture loss in high-definition surveillance environments. The TEG1008M supports desktop/wall mount installation, plug and play, no setup, easy to use, and is ideal for improving network performance.
| Network standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab |
| LED Indicator | 1* Power, 8* Link/Act |
| Interfaces | 8*10/100/1000 Base-T Ethernet ports (Auto MDI/MDIX) |
| Transmission media | Recommended: CAT5/5e UTP or better |
| Dimension | 140.0mm×66.5mm×25.3 mm |
| Material | Metal |
| Level of protection | ESD: Air discharge: ±8kV Contact discharge: ±6kV |
| Forwarding mode | Store-and-forward |
| Switch capacity | 16Gbps |
| Packet forwarding rate | 12.00Mpps |
| Buffer | 192KB |
| MAC address table | 8K |
| Power | Input: AC:190-240V 50/60Hz DC:5-12V |
| Power consumption | Max:<3W |
| Mounting | Desktop mounting: support Wall mounting: support Rack mounting:non-support |
| Environment | Operating temperature: 0°C – 45℃ Storage temperature: -40°C – 70°C Operating humidity: (10% – 90%) RH, non-condensing Storage humidity: (5% – 90%) RH, non-condensing |
| Certification | CE, FCC, RoHS |
| Protocols | CDMA/CD |
| MAC address learning | Auto-Learning and Auto-Aging |
| Funtions | plug-and-play |
*****************************************************************************************************
